GIGABYTE Ultra Durable 4 Plus makes its first appearance on GIGABYTE motherboards, with a range of features and component choices that provide record-breaking performance, cool and efficient operation and extended motherboard lifespan.
| Chipset | AMD A68H |
|---|---|
| CPU | FM2+ Socket: AMD A series processors AMD Athlon series processors |
| Form Factor | micro ATX Form Factor (22.6 x 17.4cm) |
| Memory | 2x DDR3 DIMM sockets supporting up to 64 GB of system memory Dual channel memory architecture Support for DDR3 2400(OC)/2133/1866/1600/1333 MHz memory modules Support for AMD Memory Profile (AMP)/Extreme Memory Profile (XMP) memory modules |
| Onboard Graphics | Integrated Graphics Processor: 1x D-Sub port, supporting a maximum resolution of 1920x1200 1x DVI-D port, supporting a maximum resolution of 2560x1600 Maximum shared memory of 2 GB |
| Audio | Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out |
| LAN | Realtek GbE LAN chip (10/100/1000 Mbit) |
| Expansion Slots | 1x PCI Express x16 slot, running at x16 (The PCI Express x16 slot conforms to PCI Express 3.0 standard.) 1x PCI Express x1 slot (The PCI Express x1 slot conforms to PCI Express 2.0 standard.) 1x PCI slot |
| Multi-Graphics Technology | Support for AMD Dual Graphics technology Support for AMD Eyefinity technology |
| Storage Interface | Chipset: 4x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 10, and JBOD |
| USB | Chipset: 2x USB 3.0/2.0 ports on the back panel 8x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) |
| Internal I/O Connectors | 1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 4x SATA 6Gb/s connectors 1x APU fan header 2x system fan headers 1x front panel header 1x front panel audio header 1x S/PDIF Out header 2x USB 2.0/1.1 headers 1x serial port header 1x Clear CMOS jumper 1x chassis intrusion header |
| Back Panel Connectors | 1x PS/2 keyboard/mouse port 1x D-Sub port 1x DVI-D port 2x USB 3.0/2.0 ports 4x USB 2.0/1.1 ports 1x RJ-45 port 3x audio jacks (Line In, Line Out, Mic In) |
| Operating System | Windows 8.1/7 32-bit/64-bit, XP 32-bit |
